DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry

DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry

제품 상세 정보:

원래 장소: 중국
브랜드 이름: Dupont
인증: ISO9001
모델 번호: Dupont ™ Amberlite ™ HPR650 h
문서: IER-AmberLite-HPR650-H-PDS-...en.pdf

결제 및 배송 조건:

최소 주문 수량: 1pc
가격: 협상 가능
포장 세부 사항: 표준 수출 포장
배달 시간: 5-8 일
지불 조건: t/t
공급 능력: 한 달에 60000 단위
최고의 가격 접촉

상세 정보

제품 공중 합체: 스티렌 디비 닐 벤젠 제품 매트릭스: 젤라틴
제품 유형: 강한 산 양이온 제품 기능 그룹: 술폰산
제품 용수 유지 능력: 46.0 - 52.0% (H⁺ 양식) 제품 이온 전환: h⁺ ≥ 99%
제품 사용: 전력 산업을위한 혼합 베드 탈취 응용

제품 설명

DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry

Product Description

DuPont™ AmberLite™ HPR650 H Ion Exchange Resin is a premium-quality, high-capacity resin with uniform particle size, specifically designed for use in nuclear condensate polishing mixed beds where the highest resin purity and water quality are required.

This resin offers outstanding mechanical strength and excellent oxidative stability, making it ideally suited for the high flow rate demands of condensate polishing applications. Its uniform bead size and dark color are tailored to complement the smaller, less dense, gel-type AmberLite™ HPR550 OH anion exchange resin. The distinct color difference between these two resins allows for easy visual confirmation of separation after backwashing. Together, they provide exceptional separation in mixed beds, delivering superior water quality and resin purity, which has established them as a premium mixed bed pairing in the industry.

For systems requiring exceptional resistance to surface fouling, the macroporous AmberLite™ HPR9000 OH ion exchange resin is recommended as the pairing counterpart.
DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry 0


Recommended Resin Pairings

  • Recommended Pairings:

    • AmberLite™ HPR550 OH Ion Exchange Resin (gel)

    • AmberLite™ HPR9000 OH Ion Exchange Resin (macroporous)

  • Additional Options:

    • AmberLite™ HPR550 Cl Ion Exchange Resin (gel)

    • AmberLite™ HPR9000 SO₄ Ion Exchange Resin (macroporous)


Applications

  • Mixed bed condensate polishing in PWR nuclear power plants

  • Mixed bed condensate polishing in fossil fuel power plants

  • Mixed bed polishing in industrial demineralization systems


Historical Reference

AmberLite™ HPR650 H Ion Exchange Resin was previously sold as DOWEX MONOSPHERE™ 650C (H) Ion Exchange Resin.
DuPont™ AmberLite™ HPR650 H Mixed Bed Demineralization Applications for the Power Industry 1


Typical Properties

Physical Properties
Copolymer Styrene-divinylbenzene
Matrix Gel
Type Strong acid cation
Functional Group Sulfonic acid
Physical Form Dark amber, translucent, spherical beads
Chemical Properties
Ionic Form as Shipped H⁺
Total Exchange Capacity ≥ 2.0 eq/L (H⁺ form)
Water Retention Capacity 46.0 – 52.0% (H⁺ form)
Ionic Conversion H⁺ ≥ 99%
Particle Size $
Particle Diameter 650 ± 50 μm
Uniformity Coefficient ≤ 1.10
< 300 μm ≤ 0.5%
> 850 μm ≤ 5.0%
Purity (dry basis)
Metals:
- Na (Sodium) ≤ 50 mg/kg
- Fe (Iron) ≤ 50 mg/kg
- Cu (Copper) ≤ 10 mg/kg
- Al (Aluminum) ≤ 50 mg/kg
- Heavy Metals (as Pb) ≤ 10 mg/kg
Stability
Whole Uncracked Beads ≥ 95%
Friability:
- Average ≥ 500 g/bead
- Proportion > 200 g/bead ≥ 95%
Swelling (Na⁺ → H⁺) 7%
Density
Particle Density 1.22 g/mL
Shipping Weight 785 g/L

$ For additional particle size information, please refer to the Particle Size Distribution Cross Reference Chart (Form No. 45-D00954-en).

Temperature Range (H⁺ form): 5 – 150°C (41 – 302°F)
pH Range (Stable): 0 – 14

For further details regarding recommended minimum bed depth, operating conditions, and regeneration procedures for mixed beds (Form No. 45-D01127-en) or separate beds (Form No. 45-D01131-en) in water treatment, please refer to our Technical Facts documents.
