DuPont XP 51 IG Ultrafiltration Membrane: High-Flux Industrial Water Filtration System
제품 상세 정보:
| 원래 장소: | 중국 |
| 브랜드 이름: | Dupont |
| 인증: | CE |
| 모델 번호: | Integratec ™ XP 51 IG (이전 SFP-2860XP) |
| 문서: | UF-IntegraTec-XP51-IG-en.pdf |
결제 및 배송 조건:
| 최소 주문 수량: | 1 PC |
|---|---|
| 가격: | 협상 가능 |
| 포장 세부 사항: | 표준 수출 포장 |
| 배달 시간: | 5-8 일 |
| 지불 조건: | t/t |
| 공급 능력: | 한 달에 60000 단위 |
|
상세 정보 |
|||
| 제품 브랜드: | DuPont ™ | 모델: | XP 51 IG |
|---|---|---|---|
| XP 51 IG 여과 방법: | 아웃 가압 | XP 51 Ig의 막 유형: | 중공 섬유 |
| XP 51 Ig의 막 재료: | PVDF | 다른 습식 모듈 구성 요소: | 폴리 우레탄, 폴리 에틸렌 및 폴리아이드 |
| 모듈 작동 프로세스: | 데드 엔드 | XP 51 IG 활성 막 영역: | 51 m² |
| 막 배송 중량: | 60kg | 막 무게가 비어 있습니다: | 48kg |
| 무게가 채워졌습니다: | 83kg | 제품의 적용: | 산업용 물 필터링 시스템 |
| 장점: | 고속도로 | ||
| 강조하다: | DuPont XP 51 IG ultrafiltration membrane,high-flux industrial water filtration,DOW UF membrane with warranty |
||
제품 설명
DuPont XP 51 IG Ultrafiltration Membrane: High-Flux Industrial Water Filtration System
DuPont XP 51 IG ultrafiltration membrane provides advanced separation technology for industrial water treatment applications. This high-flux membrane delivers exceptional filtration efficiency with precise molecular weight cut-off for removing particles, bacteria, and macromolecules. Designed for challenging industrial environments, it features excellent chemical resistance and prolonged service life. The membrane's optimized configuration ensures stable operation with low energy consumption, making it ideal for pretreatment in reverse osmosis systems, wastewater reuse, and process water purification across various industries.
DuPont XP 51 IG ultrafiltration membrane provides advanced separation technology for industrial water treatment applications. This high-flux membrane delivers exceptional filtration efficiency with precise molecular weight cut-off for removing particles, bacteria, and macromolecules. Designed for challenging industrial environments, it features excellent chemical resistance and prolonged service life. The membrane's optimized configuration ensures stable operation with low energy consumption, making it ideal for pretreatment in reverse osmosis systems, wastewater reuse, and process water purification across various industries.
Product Specifications
| Attribute | Value |
|---|---|
| Brand | Dupont™ |
| Model | XP 51 IG |
| Filtration Type | Out-In Pressurized |
| Membrane Type | Hollow fiber |
| Membrane Material | PVDF (Polyvinylidene Fluoride) |
| Membrane Pore Size | Approx. 0.03 µm |
| Module Operating Process | Dead-end |
| Other Wetted Components | Polyurethane, polyethylene, and polyamide |
| Active Membrane Area | 51 m² |
| Shipping Weight | 60 kg |
| Weight Empty | 48 kg |
| Weight Filled | 83 kg |
| Primary Application | Wastewater treatment |
Key Advantages
- Municipal drinking water treatment
- Industrial utility water processing
- Industrial wastewater reuse
- Municipal wastewater filtration
- RO pretreatment solutions
Product Description
The DuPont IntegraTec XP 51 IG is an advanced ion exchange membrane engineered for high-efficiency chlor-alkali electrolysis, delivering superior performance in caustic soda (NaOH), chlorine (Cl₂), and hydrogen (H₂) production.
Designed with DuPont's proprietary IntegraTec technology, this membrane ensures exceptional current efficiency (≥96%) and low energy consumption, optimizing operational costs in membrane cell electrolyzers. Its reinforced perfluorinated polymer structure provides outstanding resistance to harsh chemical environments, including concentrated brine and high-temperature conditions.
The XP 51 IG features low gas permeability and stable voltage drop, ensuring consistent output and extended service life (typically >5 years). Ideal for modern electrolysis plants, it supports sustainable production with reduced power requirements and minimized caustic impurities.
Why Choose the XP 51 IG?
Smarter Filtration, Unmatched Purity
Proprietary pore structure technology ensures superior removal of pathogens, microplastics, and colloidal particles while preserving vital minerals for safer, cleaner water outcomes.
Ultra-High Efficiency
Engineered with DuPont's cutting-edge hydrophilic polymers, the XP 51 IG achieves up to 20% higher flux rates compared to conventional membranes, translating to faster processing and energy savings.
Built for Tough Conditions
Exceptional resistance to chlorine, pH extremes, and organic fouling ensures reliable operation in industrial wastewater, brackish water, or high-turbidity applications.
Sustainable by Design
Reduced fouling tendencies and easy-to-clean surfaces minimize chemical usage and downtime, supporting eco-conscious operations and lower lifecycle costs.
Plug-and-Play Compatibility
Seamlessly integrates into modular filtration systems, offering scalable solutions for both retrofits and new installations.
