상세 정보 |
|||
| XP 77 IG 직경: | 8 인치 | XP 77 IG 막 영역 XP 77 Ig: | 77m² |
|---|---|---|---|
| XP 77 IG 재료: | PVDF | 모듈당 유량 범위: | 2.0 ∙ 8.5m3/hr |
| XP 77 Ig의 공칭 기공 직경: | 0.03 µm | XP 77 IG의 작동 압력: | 1-5 바 |
| 맥스. 이 모듈의 TMP 작동: | 2.1 바 | 이 모듈의 최대 작동 공기 수색 흐름: | 12 nm3/hr |
| 이 모듈의 NAOCL (max.): | 2,000 mg/L | 이 모델의 인증: | ISO 9001, NSF, CE |
| 애플리케이션: | 제약과 음료 | 모델의 장점: | 고성능 여과 솔루션 |
| 가장 밝은 부분: | 듀폰 XP 77 UF 막, 8 인치 PVDF 막, 제약 UF 막 | ||
제품 설명
The DuPont XP 77 IG 8 Inch PVDF UF Membrane is a state-of-the-art ultrafiltration solution designed for high-stakes applications in pharmaceuticals, beverages, and industrial water treatment. Crafted by DuPont Water Solutions, this 8-inch membrane features premium polyvinylidene fluoride (PVDF) material, renowned for its exceptional chemical resistance, mechanical strength, and thermal stability—making it a reliable choice for environments demanding uncompromising purity and long-term performance. As a key offering in DuPont’s IntegraTec™ lineup, the DuPont XP 77 IG 8 Inch PVDF UF Membrane sets benchmarks in precision filtration, effectively removing particles, colloids, and microorganisms while maintaining consistent flux rates.
The membrane operates on an outside-in filtration工艺: feed water flows across the outer surface of the hollow fibers, where contaminants as small as 0.03 µm are retained. Purified filtrate then passes through the fiber lumen, ensuring efficient separation without the need for chemical coagulants. Its innovative design allows for easy backwashing and cleaning, minimizing fouling and extending service life—reducing operational downtime and maintenance costs.
Key Specifications of DuPont XP 77 IG 8 Inch PVDF UF Membrane
|
Attribute |
Value |
|
Membrane Material |
Polyvinylidene Fluoride (PVDF) |
|
Diameter |
8 Inch |
|
Effective Membrane Area |
77 m² (829 sq ft) |
|
Max Operating Pressure |
5.0 bar (72.5 psi) |
|
Operating Temperature Range |
1–40°C (34–104°F) |
|
pH Range (Operating) |
2–11 |
|
Nominal Pore Size |
0.03 µm |
The DuPont XP 77 IG 8 Inch PVDF UF Membrane offers standout advantages: 99.99% microorganism removal ensures compliance with pharmaceutical and beverage safety standards; PVDF construction resists harsh cleaning agents, prolonging membrane life; and high flux rates optimize water production efficiency. It is widely used in pharmaceutical water purification, beverage clarification, industrial wastewater reuse, and RO pretreatment. Backed by DuPont’s global technical support, this membrane delivers a cost-effective, sustainable solution for industries prioritizing purity and reliability.
