상세 정보 |
|||
| XP 51 IG 여과 모드: | 아웃 가압 | XP 51 IG 멤브레인 유형: | 중공 섬유 |
|---|---|---|---|
| XP 51 IG 막 재료: | PVDF (폴리 비닐 리덴 플루오 라이드 | XP 51 IG 멤브레인 기공 크기: | 대략 0.03 µm |
| 모듈 작동 프로세스: | 데드 엔드 | 다른 습식 모듈 구성 요소: | 폴리 우레탄, 폴리 에틸렌 및 폴리아이드 |
| XP 51 IG 활성 막 영역: | 51 m² | XP 51 IG 운송 중량: | 60kg |
| XP 51 IG 무게 비어 있음: | 48kg | 무게가 채워졌습니다: | 83kg |
| 제품의 적용: | 폐수 처리 | XP 51 IG 장점: | 높이나 공간이 제한된 시스템 설계에 적합 |
제품 설명
Dupont UF Membranes IntegraTec™ XP 51 IG For System Designs With Limited Height Or Space
The XP 51 is a compact model in the XP series, suitable for systems with limited height or space.
1. Membrane material: PVDF
2. Nominal pore size: approximately 0.03 μm
3. Effective membrane area per module: approximately 51 m²
4. Module diameter: approximately 203 mm (8 inches), length: approximately 1520 mm (60 inches)
5. Typical operating flux is similar to the SFP2860, typically in the range of 40–110 LMH
6. Primarily used in containerized water treatment systems, small industrial RO pretreatment units, and modular equipment.
7. This model's advantage lies in its flexible system integration, suitable for standardized export equipment and customized skids.
Key Features Proven XP™ hydrophilic PVDF fibers:
• Excellent stain and chlorine resistance.
• High removal of colloidal particles, bacteria and viruses.
• Excellent filter permeability.
• Easy to clean and wet.
Optimized module design: Open platform design to fit customer-built skids.
• Short module design for height-restricted or containerized installations.
• High operating recovery rate with high air scour tolerance.
• Reduced chemical consumption through maintenance cleaning protocols.
• Rugged materials for long service life.
• Easy installation and low maintenance costs.
Product Specifications
Operating Parameters
