1,000 m³/day BWC1000 – Modular Dual‑Container BWRO Flexible Regional Water Security Desal

1,000 m³/day BWC1000 – Modular Dual‑Container BWRO Flexible Regional Water Security Desal

제품 상세 정보:

원래 장소: 중국
브랜드 이름: FG Water Technologies
인증: CE
모델 번호: BWC1000

결제 및 배송 조건:

최소 주문 수량: 1
포장 세부 사항: 기준
배달 시간: 근무일 기준 30일
지불 조건: 티/티
최고의 가격 접촉

상세 정보
정격 복구율: 70% 정격 제품 흐름: 42m³/시
RO 멤브레인 수량: 50개 컨테이너 크기: 40 + 40피트
정격 출력: 64.4kW 에너지 소비: 1.06kWh/m3

제품 설명

 1,000 m³/day BWC1000 – Modular Dual‑Container BWRO Flexible Regional Water Security Desal
The BWC1000 breaks the single‑container limit with a two‑container (40 ft + 40 ft) modular design that simplifies logistics and staging. One container houses pre‑treatment and filtration, the other the RO banks and high‑pressure pumps – together they produce 42 m³/h (1,000 m³/day). This separation allows independent servicing and future upgrades. With 50 RO membranes and an energy consumption of 1.06 kWh/m³, the BWC1000 offers a dependable, scalable supply for regional water authorities, industrial parks, and large agricultural zones.
Desal BWC500 Containerized Brackish Water Reverse Osmosis System
Key Specifications
Parameter Unit Value
Rated Product Flow m³/h 42

L/s 11.67
Rated Recovery Rate % 70
Rated Feed Flow m³/h 60
Max System Pressure barg 20
RO Membrane Spec inch 8,010*
RO Membrane Qty pcs 50
Dry Weight ton 16
Container Size ft 40 + 40
Rated Power kW 64.4
Energy Consumption kWh/m³ 1.06
Installed Power kW 103.2
Power Input – 3PH, 380V ±10%, 50Hz

*Note: membrane spec per original datasheet; confirm with manufacturer for latest.

BWC500 System Specifications Diagram
System Features

  • Twin‑container modularity – enables staged installation and easier transport.

  • Independent pre‑treatment – simplifies chemical dosing and backwash operations.

  • Integrated energy recovery – reduces pump load and extends component life.

  • IoT ready – optional sensors for predictive maintenance and operational consulting.

BWC500 System Features
Applications:
Regional water grids, industrial estates, large mining camps, major resort complexes.
