DuPont™ AmberLite™ IRC120 N Gaussian, Gel, Strong Acid Cation Exchange Resin
제품 상세 정보:
원래 장소: | 중국 |
브랜드 이름: | Dupont |
인증: | ISO9001 |
모델 번호: | Dupont ™ Amberlite ™ IRC120 NA |
문서: | IER-AmberLite-IRC120-Na-PDS...en.pdf |
결제 및 배송 조건:
최소 주문 수량: | 1pc |
---|---|
가격: | 협상 가능 |
포장 세부 사항: | 표준 수출 포장 |
배달 시간: | 5-8 일 |
지불 조건: | t/t |
공급 능력: | 한 달에 60000 단위 |
상세 정보 |
|||
제품 공중 합체: | 스티렌 디비 닐 벤젠 | 제품 유형: | 강한 산 양이온 |
---|---|---|---|
제품 기능 그룹: | 술폰산 | 제품 1 차 응용 프로그램: | 산업용 용수 완화 |
물리적 형태: | 앰버 반투명 구형 구슬 | 이온 형태 (배송 된대로): | 나이트 |
총 교환 용량: | ≥ 2.0 eq/L (na⁺ 양식) | 보수력: | 40.0 - 50.0% (Na로 형태) |
제품 설명
1. Product Overview
DuPont™ AmberLite™ IRC120 Na is a gaussian, gel-type, strong acid cation exchange resin designed for industrial water softening applications. With a long-established track record of reliable performance, this durable resin offers an optimal balance of high capacity and mechanical strength, making it ideal for co-current regenerated systems in industrial water treatment. It is also suitable for demineralization applications where the sodium form is preferred.
2. Applications
-
Industrial water softening
-
Demineralization (when sodium-form resin is specified)
3. Compatible System Designs
-
Co-current regeneration systems
4. Historical Reference
Previously sold as AmberLite™ IR120 Na Ion Exchange Resin.
5. Typical Properties
Physical Properties
Property | Specification |
---|---|
Copolymer | Styrene-divinylbenzene |
Matrix | Gel |
Type | Strong acid cation |
Functional Group | Sulfonic acid |
Physical Form | Amber translucent spherical beads |
Chemical Properties
Property | Specification |
---|---|
Ionic Form (as shipped) | Na⁺ |
Total Exchange Capacity | ≥ 2.0 eq/L (Na⁺ form) |
Water Retention Capacity | 40.0 – 50.0% (Na⁺ form) |
Particle Size Distribution
Parameter | Specification |
---|---|
< 300 μm | ≤ 2.0% |
> 1180 μm | ≤ 4.0% |
ℹ For additional particle size information, refer to Document No. 45-D00954-en.
6. Stability & Density
-
Swelling (Na⁺ → H⁺): ≤ 11%
-
Particle Density: 1.27 g/mL
-
Shipping Weight: 817 – 840 g/L
7. Operating Conditions
-
Temperature Range (Na⁺ form): 5 – 150°C (41 – 302°F)
-
pH Range:
-
Service Cycle: 1 – 14
-
Stable: 0 – 14
-
⚠ For detailed information on minimum bed depth, operating conditions, and regeneration procedures, refer to Tech Fact Document No. 45-D01131-en.
8. Hydraulic Characteristics
-
Backwash Expansion: Estimated bed expansion as a function of backwash flow rate and temperature is shown in Figure 1.
-
Pressure Drop: Estimated pressure drop as a function of service flow rate and temperature is shown in Figure 2 (valid for clean water and well-classified beds at service run start).
(Note: Refer to original document for graphical data.)
9. Safety & Compliance
-
Warning: Strong oxidizing agents (e.g., nitric acid) may degrade the resin or cause violent reactions. Consult experts before use.
-
Users should review safety data sheets (SDS) and ensure compliance with local regulations.
